The NEW 100+ Jablotron JK-107KRY starter kit including the radio module (R), LAN and GSM (Y) 4G.

+ MyCredex Support = FREE LifeTime online support service

Availability: In stock
SKU
JK-107KRY
Do you have a question about this product?
Frank

The JK-107KRY kit offers flexible setting and allows easy protection for small premises, bigger family houses, offices and companies. It is equipped with a JA-111R radio module and JA-194Y GSM module. The desired settings programmed by F-link software.


The JK-107KRY offers

  • up to 230 wireless or BUS hardwired zones
  • up to 600 user codes
  • up to 15 sections
  • up to 128 programmable outputs
  • 64 independent calendars
  • system reports to 50 users by SMS
  • 5 ARC settings
  • 5 selectable reports to ARC
  • LAN module

It has a seperate GSM/GPRS JA-194Y 4G communicator offering communication by voice, SMS or GPRS to end users or to ARC centers. It is equiped with a 1 GB memory card on the board for saving event reports, a voice menu and messages, the storage of pictures and more.

Jablotron 107KRY GSM + LAN Kit contains

JA-107KRY - controle panel, check the link JA-107KRY for more information (size 360x300x105mm);
JA-154E - wireless keypad, check the link JA-154E for more information;
JA-192E - 2x control segment, check the link JA-192E for more information;
JA-192J - 2x key tag, check the link JA-192J for more information;
JA-152A - wireless indoor siren, check the link JA-152A for more information;
JA-150P - moderne wireless movement sensor (PIR), check the link JA-150P for more information;
JA-151M - wireless magnet contact, check the link JA-151M for more information.



The JA-107KRY control unit includes:

  • 2 x BUS terminal
  • 1 x terminal for the built-in radio module (JA-111R - included)
  • 1 x terminal for the built-in GSM module (JA-194Y - included)
  • 1 connector for the LAN router


ncp insert certifications


Compare the 107KRY with the 103KRY control panel

JA-107KRY
Comparison control panels of the JA-100 alarm system
JA-103KRY
868 MHz  Communication protocol 868 MHz
230 Number of wireless or BUS hardwired zones 50
600 Number of user codes 50
15 Number of sections 8
128   Number of programmable outputs 32
64 Number of independant calenders / timers 20
50 Number of users system reports to by sms 5
360 x 300 x 105 mm Dimensions 258 x 214 x 77 mm
JA-194Y  Build in GSM / GPRS communicator JA-194Y module
yes Built in LAN communicator yes
yes (MyJablotron) App + internet (Web-Self-Service) yes
Private / Business+
Use
Private / Business

Specifications JA-107K

Control panel power supply ~ 110 – 230 V/50 – 60 Hz, max. 0.85 A with fuse F1.6 A/250 V, Protection class II
Back-up battery 12 V; 7 to 18 Ah (lead gel)
Maximum battery charging time 48 h
BUS voltage (red - black) 12.0 to 13.8 V
Maximum continuous current consumption from the control panel 2000 mA permanent
3000 mA for 60 minutes
(max. 2000 mA for one BUS)
Max. continuous current consumption for back-up 12 hours Without GSM communicator LAN – OFF: 1135 mA
LAN – ON: 1107 mA
  With GSM communicator LAN – OFF: 1100 mA
LAN – ON: 1072 mA
Max. continuous current consumption for back-up 24 hours Without GSM communicator LAN – OFF: 535 mA
LAN – ON: 499 mA
  With GSM communicator

LAN – OFF: 530 mA

LAN – ON: 494 mA

Maximum number of devices 230
LAN communicator Ethernet interface, 10/100BASE
Dimensions 357 x 297 x 105 mm
Weight with/without AKU 7027 g/1809 g
Reaction to invalid code entry Alarm after 10 wrong code entries
Event memory Approx. 7 million latest events, including date and time
Power supply unit Type A according to EN 50131-6
T 031 note: In case of a main power failure is the system backed up for 24 hours and at the same time is a failure report sent to the ARC.
GSM communicator 850 / 900 / 1800 / 1900 MHz
Classification Security grade 2 according to EN 50131-1
Operational environment Environmental class II (indoor general) according to EN 50131-1
Operational temperature range -10 °C to +40 °C
Average operational humidity 75 % RH, non-condensing
Complies with EN 50131-1 ed. 2+A1+A2, EN 50131-3, EN 50131-5-3+A1, EN 50131-6 ed. 2+A1, EN 50131-10,
EN 50136-1, EN 50136-2, EN 50581
Radio operating frequency (with the JA 11xR module) 868.1 MHz
Radio emissions ETSI EN 300 220-1,-2 (module R), ETSI EN 301 419-1, ETSI EN 301 511 (GSM)
EMC EN 50130-4 ed. 2+A1, EN 55032 ed. 2, ETSI EN 301 489-7
Safety conformity EN 62368-1+A11
Caller identification (CLIP) ETSI EN 300 089
Operational conditions ERC REC 70-03
Certification body Trezor Test s.r.o. (no. 3025)
