Jablotron JA-152NM wireless Handle Lock

Jablotron JA-152NM wireless handle lock.

A wireless module for PG outputs integrated into a mechanical lock that can be used to lock a door or window handle when the premises alarm is set. An integrated magnetic sensor allows you to monitor the closing status of a window or door.

Availability: In stock
SKU
JA-152NM

Exemption from VAT

Read the REVIEWS

Worldwide SHIPPING

Right of WITHDRAWAL

HelpDesk +31 20 7372 372
Mon to Sat 09:00 - 22:00

JA-152NM Wireless handle lock with magnetic detector

The lock offers a selectable function for automatic unlocking if a fire alarm is triggered.

  • The magnetic sensor in this module only provides information about the status of the window or door; it does not detect intrusion into the building (The product is not certified as a fully electronic security detector).
  • Before the installation of the module, suitability for particular mounting should be verified with regard to the window frame or the handle.
  • To ensure proper functioning of the handle lock the handle must be capable of being fully turned to the closed position. A window or door handle cannot be locked in the micro ventilation or full ventilation position
  • The module is a device of the JABLOTRON 100 system, is addressable and occupies one position in the system.


Specifications

Compatible with F-Link 1.4.0 and higher
Power supply 2 AA alkaline batteries (LR6) 1.5 V 2400 mAh
Warning: Batteries are not included in the product package.
Typical battery service life approx. 2 years (1 locking / unlocking a day)
Communication band 868.1 MHz, JABLOTRON protocol
Communication range approx. 300 m (free terrain)
Dimensions 229 mm x 34 mm x 18 mm
Environment II. indoor, general (in accordance with EN 50131-1)
Operating temperature range -20 °C to +60 °C
It also meets the requirements of ETSI EN 300 220-1, EN 50130-4, EN 55022, EN 60950-1
Operation conditions ERC REC 70-03
Blog Posts (1)
JA-152NM_EN_MOG51102.pdf
JA-152NM_EN_MOG51102.pdf (106.94 KB) Download
