EB-002 Conas Electric Bolt Lock with indicator LED, Fail-Safe

The Conas EB-002 is an electric bolt lock with an LED indicator LED for the closing status.

Face Plate: 205 x 35 x 3mm (LxWxD);

Strike Plate: 90 x 25 x 2mm (LxWxD)

LED Status Indicator

Autolock Time Delay: 0, 3, 6, 9 sec

Holding Force: 800kg

Availability: In stock
SKU
EB-002
€99.00 €81.82

Exemption from VAT

Read the REVIEWS

Worldwide SHIPPING

Right of WITHDRAWAL

HelpDesk +31 20 7372 372
Mon to Sat 09:00 - 22:00

The EB-002 is a electric bolt lock with status indicator LED fail-safe. The EB-002 operates according to the fail-safe principle.

The bolt is pushed out of the mechanism as soon as the lock is activated by means of the magnet: the magnet is mounted on the supplied strike plate. The strike plate is placed on the moving / opening part of a window or door. The bolt is made of hardened steel and 16mm thick. The bolt pen has a maximum holding force of 800 kg.

The bolt lock must be connected to a stabilized power supply such as the VP-PA002-EU or an access control unit such as the AC-150NET.

By using the dipswitches on the model, you can set an auto-lock delay time. This causes the pen to slide out 0, 3, 6 or 9 seconds after the magnet has made contact.

The EB-002 model is also provided with a status indicator led for showing the closing status.


Fail Safe Electric Bolt with LED

> Face Plate: 205 x 35 x 40mm (LxWxH);
> Strike Plate: 90 x 25 x 2mm (LxWxH);
> Bolt: 16mm Dia, stainless steel 16mm throw;
> Voltage: DC12V; Start Current: 900mA; Standby Current: 150mA;
> Solid Bolt: 800kg holding strength;
> Suitable for: aluminum, wooden, metal and glass doors / windows;
> Autolock Time Delay: 0.3.6.9 sec;
> LED status indicator.

EB-002 User Manual
EB-002 User Manual (523.04 KB) Download
